Economy R134a Recover, Recycle, Recharge Machine

$4,198.00

Login for special pricing 42-34288NI

Add to cart

Request a call

Click to see additional Options / Models / Accessories Available

Accessories

Click to view California Proposition 65 warning

The 34288NI combines simple operation with superior accuracy. It recovers, recycles, evacuates and recharges R-134A mobile A/C systems quickly and accurately. The product outperforms the most current SAE J-2788 standards for accuracy and efficiency, recovering more than 95% of the refrigerant in a vehicle's A/C system and charging to better than +/- 1/2 oz of the programmed charge amount.

Product Specifications:

• Dimensions: 107 cm x 61 cm x 76 cm
• Display: 5 × 9 cm (4.3-in. diag) graphical LCD
• Filter Capacity: 68 kg (150 lbs.)
• Humidity: 32.2°C (90°F), 80% RH non-condensing
• Gauges: Ø 80 mm (3.15 in.)
• Max Pressure: Maximum Pressure
• Noise: <70 dB(A)
• Operating Voltage: 115V, 60 Hz
• Oil Drain Bottle Capacity: 355 ml (12 oz)
• Operating Temperature: 10°C to 50°C (50°F to 122°F)
• Vacuum Pump: 1.5 CFM (42 L/m) @ 60 Hz
• Service Hoses: 2.75 m (9 ft) / SAE J2196
• Internal Tank Capacity: 10 kg (22 lbs.)
• Weight: 73 kg (161 lbs.)

• 34288NI ACS machine
• Operating Instructions
• Scale calibration check weight
• Service Center listing sheet
• Vacuum pump oil with global complaint SDS sheet
• Compressor oil with global compliant SDS sheet
• EPA registration sheet/envelope
• MACS 609 certification info sheet
• Mobile Vehicle A/C equipment certification form

Features

• Automatic Oil Drain: Automatically drains oil recovered during the recovery operation and puts the oil in a graduated container showing the user how much needs to be injected back into the system.
• Automatic Air Purge: Eliminates damaging air without monitoring gauges or opening valves. 4.3 in full color graphics display
• Programmable Vacuum Function: Defaults to 15 mins, programmable up to 99 mins. “Remaining time” is displayed.
• Optional Refrigerant & Oil Database: A/C system capacities for North American market vehicles (Not included with the machine)
• Refrigerant Management System: Displays refrigerant use and monitors remaining filter life. Prompts appear when 1/3 of filter life remains
• Optional Printer: Add the ability to print service summaries from the machine (Not included with the machine)
• Warranty: 1-year
