Fluid And Lube Handling
NON-METERED CONTROL HANDLE W/FLEX MEMORY 1/4TURN MANUAL NOZZLE - ATF
$184.00
44-3320-032
Click to see additional Options / Models / Accessories Available
Options
Click to view California Proposition 65 warning
Features
- Non-metered control handle for ATF flex-memory 1/4turn narrow extension/tip
- Large port, ball bearing, inlet swivel included
- Easy access fluid inlet screen included at swivel
- Included swivel hose-end cover, protects vehicle or machine surfaces from scratches
- Easy access for service of the rotary-piston mechanism
- Trigger lock button prevents accidental control valve opening and allows the control valve to be locked in open position for large volumes dispense
- Cam & Piston valve design optimized for superb control and minimum flow resistance
- Ergonomically designed grip handle for optimum comfort
- Flow Rate 0.25-8 G/M (1-40 L/M)
- Max pressure 1,450 PSI (100 bar)
- Swivel inlet 1/2″ NPT(F) Swivel
- Operating temp 14°F-140°F (-10°C-70°C)
Technical
| Weight approx. | 3.5lbs | lbs |
| Dimensions (L x W x H) | 19in L x 2in W | inch |
| Power supply | air max. pressure 1450psi | V/Hz/A |
Options
| 44-833398 | SHROUD KIT,DR, MULTI-COLORED | $25.00 | Add to cart |
