Air operated medium pressure and high delivery pump, for large installations with simultaneous operation outlets and applications that require large, constant delivery rates.
Fluids
• Synthetic and mineral based lubricants
• Hydraulic oil
• Gear oil
• Transmission fluid
Markets Served
• Very large auto and truck dealers
• Construction equipment maintenance
• Mining equipment maintenance
• Large fleets
• Railroad and mass transit vehicle maintenance
• Marine
• In plant oil distribution and transfer
Features
- Max fluid outlet pressure 1,020 psi (72 bar)
- includes pressure relief kit
- Operating air pressure 20 to 170 psi (1.5 to 12 bar)
- Air Consumption 39 cfm (1,100 Nl/min)NPT
- Air motor effective dia. 6” (150 mm)
- Air motor stroke 4” (100 mm)
- Delivery at 80 cpm 9 gal/min (35 l/min)
- Max free flow delivery 26 gal /min (100 l/min)
- Air inlet 1/2” NPT (F)
- Fluid inlet - 1 1/2" NPT (F), Fluid outlet - 3/4" NPT (F)
- Wetted materials Cast iron, aluminum, nickel, steel, polyurethane, and buna-n
- Noise level 80 dB
Technical
| Weight approx. | 42 | lbs |
| Power supply | min 29psi - max 175 psi air | V/Hz/A |
| Dimensions (L x W x H) | 36" H | inch |
