Graco's Husky pneumatic double diaphragm pumps feature a stall-free, low-pulsation air valve which provides a smooth and rapid changeover. This transfer pump handles oil transfer, oil evacuation, water, anti-freeze and windshield washer fluid with a continuous duty flow rate of 16 gpm. Typical applications include automotive dealerships, fast lube centers and service shops.
Features
- High-efficiency air valves operate at a maximum of 28 scfm.
- Center and end porting options available.
- Up to 15 ft. of suction lift provides installation flexibility.
- Groundable to reduce risk of static and electric shock.
- Wetted Parts: Buna-N, Acetal, Aluminum, Stainless Steel, PTFE, Zinc-Plated Steel
- 5 Year Warranty. See manufacturers website for details.
- Maximum Flow Rate: 16 gpm
- Maximum suction lift: 15 ft (4.5 m) dry, 25 ft (7.6 m) wet
- Air pressure operating range: 25-100 psi (1.8-6.9 bar, 0.18-0.69 MPa)
- Air inlet size: 1/4 npt(f)
- Fluid inlet/outlet size: 3/4 in npt(f)
- Weight: 8.5 lb. (3.9 kg)
Technical
| Weight approx. | 11 | lbs |
| Dimensions (L x W x H) | 9.6 x 7.2 x 12 | inch |
