Tire And Wheel Service
Coats 1600 Direct Drive Wheel Balancer, 220V, 60Hz, 1Ph, 40mm
$10,133.00
68-80016003D
The 1600 ProBalance Technology employ’s a unique balancing algorithm in combination with the most reliable and accurate balancing systems & technologies to simultaneously minimize BOTH static and couple unbalance.
Features
- Direct Drive.
- Probalance Technology.
- Touchscreen.
- Stop, Lock and Index.
- Speed Thread.
- Laser Guided Operation.
- LED Barrel Lighting.
- Operator Language Selection.
- Behind The Spoke Function.
Technical
| Tire width | 2" - 20" | inch |
| Wheel weight, max. | 160 | lbs |
| Motor output | 1 | kW |
| Measuring time | 6 | s |
| Weight approx. | 650 | lbs |
| Rim width | 2" - 20" | inch |
| Rim diameter | 8" - 30" | inch |
| Color | Red | |
| Power supply | 220V, 60Hz, 20A, 1Ph | V/Hz/A |
| Balancing accuracy | 1g/.01oz | g |
| Balancing speed | 245 | rpm |
| Dimensions (L x W x H) | 55" x 57" x 75" | inch |
| Tire diameter | 44" | inch |
| Balancing programs | 8 |
Options
| 68-8113277C | Light Truck Cone Kit | $311.00 | Add to cart |
| 68-8114386 | Short Pins | $149.00 | Add to cart |
| 68-85610104 | Adjustable Pin Plates | $1,549.00 | Add to cart |
Accessories
| 68-8112106 | Small Pressure Cup & Rubber Lip | $62.00 | Add to cart |
| 68-8112107 | Spring | $13.00 | Add to cart |
| 68-8113390 | Scraper | $9.00 | Add to cart |
| 68-8309011 | Calipers | $95.00 | Add to cart |
| 68-85607780 | Premium Wheel Weight Hammer | $29.00 | Add to cart |
| 68-85608312 | No Mar Ring | $29.00 | Add to cart |
| 68-85608850 | Weight Tray Studs - 3 | $7.00 | Add to cart |
| 68-85609499 | 8 Double Sided Collets (2.03" - 5.31" | $684.00 | Add to cart |
| 68-85610715 | Side Shadow Board | $191.00 | Add to cart |
| 68-85610908 | Premium Hub Nut | $162.00 | Add to cart |
