Fluid And Lube Handling
Electric Cord Reel, 40' x 12 gauge, 20 amps, GFCI Duplex Outlet
$1,039.00
44-2510-013
Click to view California Proposition 65 warning
These cord reels are designed for use in dealerships.
*Multi- positioning Outlet Arm – provide ease of changing from ceiling to base mount: five positions for any application and mounting configuration.
*Easy spring tension can be adjusted on site by adding or removing cord wraps easily from the reel.
*Industrial grade collector ring, replaceable carbon brushes, and brass transfer rings
Features
- Adjustable ball stop allows user to set height of the retracting cord
- 5.5’ power inlet cord with grounded plug
- SJTO Cord. Cord is rated to 300 volts and has a temperature range of –20ºC to 60ºC
- Indoor use only - Dry Location
- Cord Length 40' (12.9 m)
- Gauge 12/3 SJTO
- Inlet Cord 5.5' (1.67 m) 12/3 SJTO
- Plug NEMA 5-20P Grounded
- Amps 20
- Receptacle NEMA 5-20R GFCI Duplex
Technical
| Dimensions (L x W x H) | 12.5" X 9 X 13.25 | inch |
| Power supply | 115V / 60Hz / 20A | V/Hz/A |
| Weight approx. | 30 | lbs |
