Fluid And Lube Handling
Fire-Ball 300 15:1 Stationary 400 lb Pneumatic Undercoating/Rust-Proofing Pump Package
$2,958.00
11-226269
Click to view California Proposition 65 warning
Stationary undercoating package for 400 lb (180 kg) container includes pump (206700), dispense kit (222082), tip (286517), 25 ft (7.6 m) hose length, cover (200326).
Features
- Maximum Working Pressure: 2700 psi (186 bar)
- Fluid pressure ratio: 15:1
- Air operating range: 40 to 180 psi (3 to 12 bar)
- Air motor effective diameter: 3 in. (76 mm)
- Stroke: 3 in. (76 mm)
- Air consumption: 17 cfm/gallon pumped at 100 psi
- Pump cycles per gallon (liter): 90 (24)
- Delivery: 0.66 gallons/minute (3 liters/minute)
- Maximum recommended pump speed: 66 cycles/min;0.7 gpm (32 liter/min)
- Recommended speed for optimum pump life: 15 to 25 cycles per min
- Wetted parts: Carbon Steel, Brass, Copper, Aluminum, PTFE, Nitrile Rubber, Leather
