Premium Hose Reel for the toughest shop environments
Today’s heavy-duty hose reel market demands an innovative use of components that provide long life, improved serviceability, and superior structural design. Our Premium reel incorporates advanced design features that ensures long life in the toughest environments while reducing overall weight. All Premium series reels have a narrow design; includes hose, hose stop, and a 2.5’ connecting hose.
Air & Water Low Pressure 300 PSI for delivery of air, water, and anti-freeze.
Fluid Inlet Port
1/2″ NPT (F) swivel
Fluid Outlet Port
1/2″ NPT (F) swivel
Outlet Thread
1/4″ NPT (M) for 3/8″ ID hoses
1/2″ NPT (M) for 1/2″ ID hoses
Wetted Materials
Brass, Acetal and Buna-N™
Features
- Superb Corrosion Resistance
- Superior Structural Design and Stability
- Fully Ported Shaft and Pressure Balanced Swivel
- High Quality Long Life Power Spring
- Spool Mounted on Dual Ball-Bearings
- Rectangular Hose Guide Outlet with Rollers
- 7–Position Outlet Arm & 12-Position Latching Mechanism
- Easy Maintenance and Service
- Easy Installation Mounting and Accessories
Technical
| Dimensions (L x W x H) | 20.5 x 6.75 x 21.5 | inch |
| Weight approx. | 64 | lbs |
