Brake Service
Click to see additional Options / Models / Accessories Available
Options
FluidPRO BFX-20 Brake Fluid Exchanger delivers complete brake fluid exchange in a simple process, unlike most competitive models. Compatible with both ABS & non-ABS brake systems, it is easy to operate with service times of 10 minutes.
Features
- New brake fluid pumped from supplied 5L/1.3 gallon reserve tank, transfer of fluid is not required.
- Variable pressure regulator.
- Brake Master Cylinder fluid extractor.
- Suitable for ABS, ESP , EDS, and SBC.
- Equipped with a hydraulic pump.
- Automatic switch-off on empty container.
- Pulsating fluid flow to pressurize air bubbles out of the braking system.
- Pressure-less decoupling from vehicle.
- Venting of device during container changeover is not necessary.
- Removable shelf for adapters and tool storage.
- Quick evacuation of waste brake fluid to speed up brake fluid change.
- Reduced system back pressure lessens the likelihood of fluid spill and/or spray when removing hoses from the adapters.
Technical
| Power Connection | 110 | V |
| Vaccum or Pressure Bleed | Pressure | |
| Weight approx. | 46 | lbs |
| Power supply | 110V, 60Hz | V/Hz/A |
| Dimensions (L x W x H) | 40”H x 16”W x 16”L | inch |
Options
| 362-025 80523 00 | Fuse 6.3 AMP Slow blow | $15.00 | Add to cart |
| 362-026 80798 00 | Gear pump | $278.00 | Add to cart |
| 362-425 80014 00 | Unit BFX-20 Brake Fluid Exchange w/ All makes Adapter set | $2,140.00 | Add to cart |
