Fluid And Lube Handling
Tank Monitoring
$576.00
44-3110-033
Click to see additional Options / Models / Accessories Available
Options
Click to view California Proposition 65 warning
Standalone tank controller with 4 channels capable of controlling up to 4 different tanks or fluids. Each channel can connect to a solenoid valve, remote alarm or strobe light.
The TM Control can be used as a high or low-level control to prevent overflow, or as a pump shutoff to prevent the pump from running dry, and allowing air to enter the system.
Features
- Controls up to four channels. Each channel can be assigned to a different tank, or multiple channels can be assigned to a single tank
- Each channel controls solenoid valves, relays, external alarms, etc.
- This unit can be a standalone unit; no need to connect to auxiliary software or systems
- TM Control works with Tank alert strobe light and alarm 3120-029
- One button for setup, resetting alarms, and system test
- Use the key switch for bypass mode control, setup access, or rebooting the system
- Status LEDs: yellow indicates bypass mode and white on indicates system status; on
- Input LED for each channel; red blinking LED indicates level warning
- Outputs can be configured to “normally- open” or “normally closed”
Technical
| Power supply | 115/230Vac 50/60Hz | V/Hz/A |
| Dimensions (L x W x H) | 48 x 4 x 4 | inch |
| Weight approx. | 4 | lbs |
Options
| 44-3120-029 | Tank Alert Strobe Alarm | $72.00 | Add to cart |
| 44-3120-092 | TM Control - Tank Sensors 1 Level Sensor, Switch, Single Probe, 5.6 ft. with 33 ft. cable | $219.00 | Add to cart |
| 44-3120-093 | 2 Level Sensor, Switch, Double Probe, 3 ft. & 5.5 ft. with 33 ft. cable | $388.00 | Add to cart |
| 44-3120-094 | 1 Level Sensor, Switch, Flex Adjustable Single Probe, 16 ft. cable | $341.00 | Add to cart |
| 44-3120-225 | VALVE, SOLENOID, NO, AIR, 24VDC | $381.00 | Add to cart |
