Fluid And Lube Handling
CenterFlo 50 (CF50) Aluminum
$901.00
44-1120-037
Click to see additional Options / Models / Accessories Available
Options
Click to view California Proposition 65 warning
CF50 is a high performance 1” AODD pump with many unique features. Similar to all our CF series pumps, the new CF50 utilizes a flow through fluid design that is more air efficient than traditional AODD pumps. Capable of distributing up to 50 gal/min. This equates to higher performance, versatility along with easy serviceability.
Features
- Air inlet 3/8" NPSM (F).
- Fluid inlet port 1" NPT(F)
- Fluid outlet port 1" NPT(F)
- Max. free flow 53 Gal/min (200 l/min)
- Operating air pressure range 22 –102 PSI (1.5–7 bar)
- Solids in suspension - 1/8" (3.2 mm)
- Wetted Materials Aluminum, Stainless steel, Hytrel, Acetal, and Buna-N.
Technical
| Weight approx. | 30 | lbs |
| Power supply | 22-102 psi | V/Hz/A |
| Dimensions (L x W x H) | 11 x 11 x 12.13 | inch |
Options
| 44-1121-024 | CF50 Evacuation outfit for Oil | $1,719.00 | Add to cart |
| 44-1121-029 | CF50 Alum Wall Mount Package for Anti-freeze & Windshield Wash Solution | $1,763.00 | Add to cart |
| 44-3270-120 | 3/8" NPT(f) ARO Series coupler | $39.00 | Add to cart |
| 44-3270-123 | 1/4" NPT(f) ARO Series nipple | $14.00 | Add to cart |
| 44-4411-012 | Bung Kit for 1" OD Suction Tubes | $130.00 | Add to cart |
| 44-4411-036 | WALL MOUNT, CF-50 | $179.00 | Add to cart |
