Fluid And Lube Handling
Pump, Diaphragm, 1", CF-30, DEF
$869.00
44-1120-031A
Click to see additional Options / Models / Accessories Available
Options
Click to view California Proposition 65 warning
CenterFlo pumps can handle a wide range of fluids used for vehicle service. Pump air valve module and lateral pump covers are manufactured in polypropylene models.
They can be used as stand-alone pumps for transfer applications or as systems pumps in distribution systems that include hose reels
Features
- Recommended Applications Fluid dispensing, transfer, evacuation, and distribution systems
- Recommended fluids: DEF
- Wetted Materials: Teflon, Viton, Polypropylene, Stainless Steel, and Hytrel
- Air inlet 3/8" NPSM (F)
- Fluid inlet port 1" NPT(F)
- Fluid outlet port 1" NPT(F)
- Max. free flow 28 gal/min (106 l/min)
- Operating air pressure range 22 –102 PSI (1.5–7 bar)
- Solids in suspension 3/16" (3 mm)
Technical
| Power supply | 22 to 102 psi | V/Hz/A |
| Dimensions (L x W x H) | 8.5 x 8.58 x 9.06 | inch |
| Weight approx. | 16 | lbs |
Options
| 44-1210-057P | AODD CF15 Drum Package | $1,904.00 | Add to cart |
| 44-3270-163 | ADAPTER,H BARB 1"GAS M TO 3/4" BARB | $23.00 | Add to cart |
| 44-3340-015 | NOZZLE, MANUAL- DEF - 1" BARB | $62.00 | Add to cart |
| 44-4411-025 | KIT, WALL MOUNT, CENTER FLO PUMPS | $46.00 | Add to cart |
| 44-4530-046 | KIT, RSV, SS, SUCTION 330 TOTE | $495.00 | Add to cart |
| 44-8561-012 | HOSE, ASSY 3/4" DEF DISCH W/1 FITTING | $152.00 | Add to cart |
| 44-8570-006 | HOSE, DEF SUCTION-3/4" W/ HOSE CLAMPS | $57.00 | Add to cart |
