The PicoScope 4-Channel Advanced kit not only includes the industry-leading automotive oscilloscope, the PicoScope 4425A, but it also offers the best of the diagnostic accessories available from Pico Technology, all in one package.

It provides efficient voltage and current analysis of vehicle electrical and electronic systems to quickly find and confirm a wide range of potential faults. It can be used to view signals from the ignition system, sensors, actuators and communications networks, as well as for CAN and FlexRay protocol decoding.

The PicoScope 4425A connects to a variety of intelligent probes using PicoBNC+ to provide accessory power and configuration assistance. Linked to your PC by a super-fast USB 3.0 cable, it is controlled by our PicoScope 7 user interface that features a robust set of tools for precision signal capture and analysis, plus access to over 150 Guided Tests and a growing library of reference waveforms.

Typical Applications:

• Test vehicle components/systems with minimal teardown.
• Find troublesome intermittent faults.
• Investigate issues with no, multiple, or misleading fault codes.
• Diagnose charging and starting faults.
• Trace problems with actuators not monitored by the ECU.
• Identify mechanical problems.
• Develop objective data for manager/customer discussions.
• Part of proven NVH solution.

Kit Includes:

• (1) PicoScope 4425A 4-Channel Automotive Oscilloscope
• (1) 1.8m USB 3.0 Cable
• (1) 4.5m USB 2.0 Cable
• (1) PicoBNC+ 3M Test Lead Set, Blue, Red, Green, Yellow
• (2) PicoBNC+ Automotive 10:1 Scope Probe & Adaptor
• (1) S Hook
• (1) Extension Lead For Maxi Style Fuses
• (1) Extension Lead For Mini Style Fuses
• (1) Breakout Lead For ATC Style Fuses
• (1) Extension Lead JCASE Style Fuses
• (1) Probe & Clip Kit, Black
• (1) Probe & Clip Kit, Red
• (1) Large Dolphin Clip, Black
• (1) Large Dolphin Clip, Red
• (1) Electronics Acupuncture Probes
• (1) PicoBNC+ Current Clamp: 2000A AC/DC
• (1) PicoBNC+ Current Clamp: 60A AC/DC
• (4) HT Extension Leads
• (1) Earth Wire For Coil Pack
• (1) 2-Wire Breakout Lead
• (1) 2-Pin ACS Connector Breakout Lead
• (1) Ultrasonic Parking Sensor Detector
• (4) PicoBNC+ Secondary Ignition Pickup
• (1) PicoBNC+ Resistance Test Lead
• (1) PicoBNC+ Wide-Range Temperature Probe
• (1) PicoBNC+ COP & Signal Probe
• (1) Premium 6-Way Breakout Lead Set
• (1) Carry Case



Features

• 400MS/s sampling rate.
• 250M samples memory buffer.
• ±50 mV to ±200 V in 12 ranges.
• Probe mismatch warning.
• 2-Year warranty.
• Floating inputs.



Technical

Weight approx.	15	lbs
Power supply	Powered from PC USB connection	V/Hz/A
Dimensions (L x W x H)	19 x 16 x 7	inch
