10,000 lb. in-ground SmartLift with truck adapters, Shockwave DC power, with bench-mounted housing for batteries.

Truck adapter SmartLift option not needed by most OEM's but is sometimes ordered by dealers for other reasons. For lifting vehicles on frames.



Features

• 10,000 lb. lifting capacity.
• Truck adapters for lifting body-on-frame vehicles.
• Shockwave equipped with DC power, faster rise and descent time.
• Bench-mounted controls enclosed in fireproof containment.
• Polymer containment housing protects lift from environment.
• In-ground components are accessible at floor level for servicing.
• Locking system every 3" and has lower to lock function.
• Smartguard coating to protect plungers from corrosion.



Technical

Dimensions (L x W x H)	108-1/4" x 42-1/2" x 4"	inch
Power supply	110v/60Hz/5 amps	V/Hz/A
Color	Red, blue or black
Lifting/lowering time approx.	25/19	s
Lifting height	75" to 76-1/4"	inch
Oil fill capacity	5	gallons
Support piston diameter	8"	inch
Load carrying capacity	10,000 lbs	lbs
