BendPak HDSO14P 14,000-Lbs. Capacity Open-Front 4-Post Lift
$8,718.00
Click to view California Proposition 65 warning
BendPak's HDSO14P is an open-front four-post lift that features clear entry upfront, providing easy vehicle access. A generous 14,000 lbs. lifting capacity and extended runways allow you to service a wide variety of vehicles, ranging from small cars to full-size trucks. We engineered the HDSO14P without a front cross bar, so operators can easily enter and exit from beneath the vehicle. Now the process of front-end adjustment becomes quick and trouble-free.
This model is a must-have for busy alignment bays. For precise front-lift leveling nothing beats our patented adjustable front outrigger tubes. The infinitely adjustable pitch compensates for excessive loads and unlevel floors. Four heavy-duty, high-quality, stainless steel lifting cables and a single hydraulic cylinder mounted underneath the runway make this lift the most durable, maintenance-free lifting system on the market. Huge 10.5" diameter cable sheaves within the runway and cross tubes work with massive 2.25" sheave axles to improve cable wear and critical component lifespan. Dual-hub cable sheaves reduce stress, fatigue, and wear. Naturally, this means a lot less money in service-related expenses down the road.
The HDSO14P is equipped with multiple adjustable height locking positions for variable-height parking. A convenient push-button pneumatic safety lock control releases all four independent safety locks simultaneously. Each lift is supplied with four high-quality 1/2" diameter, 6 x 25 stainless steel lifting cables rated at 14,000 lbs. each. The combined rating of these cables is more than 411% of the maximum lifting capacity of the entire lift! this aircraft-quality cable was specifically designed for lifting application and provides a great balance between abrasion resistance and fatigue. And we make sure it looks tidy too - all lifting cables are fully enclosed within the lift structure itself.
Features
- 14,000-Lb. Lifting Capacity.
- CE Approved and Certified. Meets or Exceeds the Standards Prescribed By European Standard EN 1493.
- Huge Cable Sheaves Reduce Wear and Tear.
- Extended Runway Length for Servicing.
- Longer Approach Ramps for Low Ground Clearance Vehicles.
- Extremely Convenient Open-Front Design for Easy Access.
- Single Hydraulic Cylinder Mounted Underneath Runway.
- Runways Adjust for Different Tread Widths.
- Longer Approach Ramps for Low Ground Clearance Vehicles.
- Shipping Dimensions - 221"(L) x 22"(W) x 35"(H).
Technical
| Load carrying capacity | 14,000 | lbs |
| Weight approx. | 3,238 | lbs |
| Color | Grey | |
| Power supply | 208-230V / 60 Hz / 1 Ph | V/Hz/A |
| Dimensions (L x W x H) | 244.5 x 143.25 x 103.25 | inch |
