The RIC-4716 inflation cage is designed using 2-3/8” diameter, high-yield, seamless steel tubing with expansion properties to ensure strength, durability and safety. The gradual upper-arched mandrel bent tube design yields maximum space and is engineered to withstand and contain wheel and tire projectiles under extreme tire ruptures, preventing potential injuries or deaths.

The RIC-4716 stands 49-1/2” tall and 21” wide and features four welded-steel bars in order to meet the demands of all wheel service shops. It can handle tires with a maximum width of 16” and maximum diameter of 47”, delivering full-capability performance. A solid-steel welded-steel base features a full-width angle-iron wheel cradle to keep the wheel safely contained within the inflation cage during all inflation procedures.



Features

• Accommodates Hub Assemblies Up to 9.5” Wide.
• 2-3/8” Diameter, High-Yield, Seamless Steel Tubing.
• 4-Bar Welded-Steel Construction.
• Four Tubular Steel Base Frame Supports Keeps Cage Elevated Off the Floor to Prevent Rust and Corrosion.
• Full-Width Angle-Iron Wheel Cradle.



Technical

Tire diameter	47	inch
Tire width	16	inch
Weight approx.	256	lbs
Color	Red
Dimensions (L x W x H)	30 x 24 x 60	inch
