Features

• Dynamic, Static, ALU1, ALU2, and ALUS for total compatibility with steel and aluminum wheels.
• Integrated pneumatic wheel lift handles up to 330 lbs. for easy mounting and reduced strain on technicians.
• High-precision 64-bit digital architecture and single-chip control system for ultra-fast data processing.
• Rugged 40 mm precision-machined, hardened-steel shaft ensures long-term durability and repeatable clamping.
• Self-centering quick-chuck system dramatically reduces setup time and improves centering accuracy.
• Electro-pneumatic braking system locks wheels for pinpoint weight placement at top or bottom dead center.
• Optional lower laser projects 6 o'clock placement for adhesive weights in ALU modes.
• Top-dead-center LED weight placement indicators guide fast and accurate clip-on weight installation.
• Supports wheels up to 49.25" in diameter, 20" wide, and up to 330 lbs in weight.
• Dual-unit display allows user preference between gram/ounce and inch/millimeter readouts.
• 7–10 seconds for car wheels, approximately 20 seconds for truck wheels.
• Built-in optimization mode improves balance on problematic wheels using tire rotation guidance.



Technical

Dimensions (L x W x H)	70 x 67 x 65	inch
Balancing accuracy	2.5	g
Color	Gunmetal Grey
Measuring time	20	s
Motor output	230 VAC, 19A, 60 Hz, 1 Ph. 1.1kW	kW
Wheel weight, max.	330	lbs
Tire diameter	49.25	inch
Balancing programs	Dynamic, Static, ALU1, ALU2, and ALUS
