12K Cap. / Clearfloor / High-Rise / Triple-Telescoping Arms.



Features

• Massive 12,000-lb. lifting capacity for cars, trucks, SUVs, vans, and EVs.
• Triple-telescoping Bi-Metric swing arms provide both symmetric and asymmetric lifting configurations from a single lift.
• Automatic Swing Arm Restraint System (ASARS) locks arms securely in place using forged steel teeth for improved stability and safety.
• High-rise lifting design delivers up to 82.5 inches of lifting height for comfortable undercar access.
• Clearfloor configuration eliminates floor obstructions and allows easy movement of transmission jacks and tool carts beneath vehicles.
• Low-profile arm design reaches OEM lifting points on low-sitting sports cars and modern EVs.
• Wide or narrow installation options allow the lift to fit different shop layouts and bay sizes.
• Ergonomic single-point safety lock release simplifies lowering procedures and improves operator convenience.
• Includes a 12-piece adapter set for handling a wide variety of chassis and frame configurations.
• Column-mounted adapter storage racks keep lift adapters organized and easily accessible.
• Available extra-tall 12APX-192 version provides added clearance for high-roof vans and taller commercial vehicles.
• Backed by BendPak’s 5-2-1 warranty coverage for long-term durability and shop confidence.



Technical

Dimensions (L x W x H)	156 x 28 x 169	inch
Power supply	208-240 V / 60 Hz / 1 Ph	V/Hz/A
Weight approx.	2423	lbs
Lifting/lowering time approx.	45	s
Lifting height	82.5	inch
Motor output	2.2	kW
Effective height	75.75	inch
Oil fill capacity	3	gallons
Load carrying capacity	12,000	lbs
Drive-over height	4	inch
