The addition of a WPS500X provides you with that same detailed insight into the engine system for accurate diagnosis of common problems such as:

• No start
• Loss of power
• Misfire
• Stalling
• Engine noise
• Emissions fault
• Backfire

With the unparalleled resolution and accuracy of the WPS500X Automotive Pressure Transducer you can perform quick and accurate pressure analysis on many automotive systems.

• Accurately measure up to 500 psi (34 bar).
• Ultra-fast 100 µs response time.
• Zoom function for enhanced analysis capabilities.
• Internal rechargeable LiPo battery.
• Integrated pressure relief / bleed-off valve.
• Auto zeroing.
• High noise immunity.
• Temperature compensated.

The WPS500X features an extremely fast 100 µs response time from 0% to 90% of full scale and sensitivity down to about 0.07 psi (5 mbar). This provides you with an accurate representation of rapidly changing signals that span a broad pressure range.

Use the WPS500X with PicoScope to reveal how your engine is actually performing with minimal intrusion. Compression, airflow, valve timing and back pressure can all be measured in one hit.



Technical

Dimensions (L x W x H)	16x12x5	inch
Weight approx.	8	lbs



Replacement / Service Parts

733-PA094	WPS500X Carrying Case - 16x12x5	$178.00	Add to cart
733-PP972	Vacuum tap for WPS500X	$58.00	Add to cart
733-PP973	Fuel hose pressure tap for WPS500X (small)	$58.00	Add to cart
733-PP974	Fuel hose pressure tap for WPS500X (Medium)	$58.00	Add to cart
733-TA071	WPS500X (Transducer only)	$991.00	Add to cart
733-TA081	Charging Cable: USB A male to mini 5 pin 2m	$6.00	Add to cart
733-TA083	Fuel pressure test hose for WPS500, large Schrader valve	$55.00	Add to cart
733-TA085	Vacuum hose adapter for WPS500X	$31.00	Add to cart
733-TA086	PicoScope WPS500X Bleed hose	$31.00	Add to cart
733-TA087	Exhaust adapter for WPS500X	$61.00	Add to cart
733-TA117	Fuel pressure test hose, small Schrader valve	$55.00	Add to cart
733-TA129	Universal vacuum hose adapter	$13.00	Add to cart
733-TA130	Cable: insulated BNC to insulated BNC 5m	$43.00	Add to cart
733-TA142	Foster 2 series 1/8" coupler w/valve, male NPT	$17.00	Add to cart
733-TA212	Standard compression hose (for WPS500X, w/universal tip)	$109.00	Add to cart
733-TA213	M10 Short Reach Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA214	M10 Deep Reach Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA216	M12 Deep Reach Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA217	M14 Short Reach Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA218	M14 Deep Reach Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA219	M16 Ford Triton Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA220	M18 Short Reach Adaptor for Standard Compression Hose (TA212)	$43.00	Add to cart
733-TA224	Adaptor AST to WPS500X compression hose	$136.00	Add to cart
733-TA229	Adapter for WPS500X to AST equipment	$67.00	Add to cart
733-TA250	WPS500X Adaptor Kit B	$131.00	Add to cart
