Tire And Wheel Service
The EHP System IV-E tire changer can handle a wide range of passenger car and light truck wheel and tire assemblies, from OEMs or aftermarket. It features pneumatic locking of the mount/demount head offset, which provides maximum cosmetic safety for expensive wheels and significantly reduces the risk of wheel or tire damage.
Features
- Ergonimically-Positioned Bead Breaker Control -- Pedal is positioned away from the bead breaker with a guard, preventing the operator from accidentally stepping on and activating it while standing next to the bead breaker.
- Integrated Pressure Limiter -- Stops air flow once pressure has reached 55 PSI (3.5 Bar), thereby preventing accidental tire over-inflation.
- Adjustable Four-Jaw Clamp -- Self-centering nylon-covered clamps grip securely and protect the wheel. Reduced-angle jaws ensure no slippage. Air inflation jets assist bead seating.
- Extra Wheel Protection -- Replaceable nylon inserts for demount heads prevent wheel scratching.
- Twin-Cylinder Clamping -- Two powerful clamping cylinders provide uniform clamping pressure and increased clamping power.
- Bead Breaker -- Provides precise power and can be toggled with the foot pedal as needed. Both the stiffest and the softest sidewalls are a snap. No damage to tire while loosening the bead.
- Optional Safety Restraint Arm -- Positively restrains wheel and tire assembly to the tire changer during the inflation process and reduces potential for injury by the unlikely event of wheel or tire failure.
- Optional Pneumatic Bead Assist -- The optional Pneumatic Bead Assist features a three-piece design with a Top Roller, Pressing Foot, and Lifting Disc.
- Each piece provides a specialized function that assists a single operator in mounting/demounting low-profile tires.
Technical
| Rim diameter | 10 - 24 outer clamping diameter range | inch |
| Rim width | 15 maximum | inch |
| Power supply | 120 1 Ph / 60 | V/Hz/A |
| Dimensions (L x W x H) | 72 x 78 recommended floor space | inch |
| Tire diameter | 40 maximum | inch |
| Weight approx. | 960 | lbs |
