Vehicle Lifts
14,000 lb Shockwave Drive-On Lift, Ex Long, Open
$15,328.00
39-SMO14EL2-SW
Click to see additional Options / Models / Accessories Available
Options
Click to view California Proposition 65 warning
Shockwave Equipped, open front surface-mounted drive-on lift with runways. 14,000 lb. capacity. Accommodates maximum wheel base of 215". DC powered motor.
Features
- Shockwave equipped, DC power, (2) 24 series batteries needed, not included.
- 2x's faster rise and descent speed.
- 110v built-in battery charger.
- Wallmount laser to assist in spotting vehicles.
- Multiple power-unit mounting options.
- Open front design for easy access under vehicle.
- 20" wide runways.
- 78-3/4" rise.
- 215" maximum wheel base.
- Louvered ramps with polymer rollers for improved traction while pulling on.
- Hammer-tone powder coat paint for improved durability.
Technical
| Drive-over height | 8-1/4 | inch |
| Load carrying capacity | 14,000 | lbs |
| Lifting height | 78-3/4 | inch |
| Lifting/lowering time approx. | 35 | s |
| Weight approx. | 2500 | lbs |
| Track length | 208 | inch |
| Track width | 20 | inch |
| Power supply | 110 / 60 / 5 | V/Hz/A |
| Dimensions (L x W x H) | 286 x 150-1/2 x 109 | inch |
Options
| 39-SMO14L-SW | 14,000 lb Open Front 4 Post 182" WB Shockwave | $14,701.00 | Add to cart |
