Hybrid Multimeter, 1000V CAT III

$363.00

16-3990

Add to cart

Request a call

OTC 1000V CAT III Hybrid Multimeter with Insulation Resistance Test. A full function Multimeter with an insulation test feature is used to test for voltage leaks through insulation found on Hybrid and Electric Vehicles.

Specifications:

• Insulation Testing Voltage: 50V, 100V, 250V, 500V, 1000V
• AC Voltage: 6V, 60V, 600V, 1000V
• DC Voltage: 6V, 60V, 600V, 1000V
• DC Millivolts: 60mV, 600mV
• AC Current: 60mA, 600mA
• DC Current: 60mA, 600mA
• Ohms: 600., 6k., 60k., 600k., 6M., 40M.
• Capacitance: 10nF, 100nF, 1000nF, 10μF, 100μF
• Frequency at mV range: 60Hz, 600Hz, 6kHz, 60kHz, 600kHz, 1MHz
• Frequency at DCV/ACV range: 10Hz ~ 100kHz
• Temperature: -40C to + 537C (-40F to + 998F)

Kit Includes: Heavy Duty Class III test leads with alligator clips, Short Lead, K Type temperature adapter and Manual.






Features

• Hybrid Insulation Resistance Test.
• True RMS.
• Auto Ranging.
• Diode Test.
• Continuity Buzzer.
• Data Hold.
• Data Logging.
• Display Backlight.
• Min/Max Mode.
• Sleep Mode.
• Low Battery Display.
• Warranty: 1 year.
