Graco 24G576 LD Series 3:1 Pneumatic Oil Pump - Universal
$677.00
11-24G576
Click to see additional Options / Models / Accessories Available
Options
_web.jpg)
Click to view California Proposition 65 warning
These affordable, full-featured pumps are designed for low to medium volume applications and perfect for a single fluid dispense or roll around solution. LD pumps are fine-tuned for a compact, flexible and durable solution pumping petroleum and synthetic-based oils (motor, gear and ATF) up to 7.8 gpm. Typical applications include automotive dealerships, fast lube centers, and service shops.
Features
- Three Inch Air Motor providing more power for a better flow
- Patented cup and plate design eliminates the need for O-rungs that wear faster for a more durable, long-lasting solution
- Modular air valves are easy to configure for hassle free installation
- Patented self cleaning design increases reliability and minimizes pressure drop with rapid change over for reduced stalling and smoother flow
- Includes: Bung Adapter (24F918)
- 5 Year Warranty. See manufacturers website for details.
- Approximate Free Flow Rate: @ 100 psi 7.8 gal/min (30 liters/min)
- Approximate Air Use and Flow @ 100 psi (80 cpm): 18 scfm @ 2.8 gpm (0.51 m ³/min @ 10.6 lpm)
- Air Inlet: 1/4" npt (f), Fluid Inlet: 1" npt (f), Fluid Outlet: 1/2" npt (f)
- Air Operation Range: 20-150 psi (1.37-10.3 bar)
- Cycles per Gallon/Liter: 29 cpg / 7.7 cpl
- Wetted Parts: Zinc plated carbon, steel, aluminum, nitrile, polyurethane, nickel plated aluminum
Technical
| Weight approx. | 10 | lbs |
| Dimensions (L x W x H) | 18 x 7.2 x 9.6 | inch |
