Vehicle Lifts
With a loading capacity of 12,000 lbs., the 12k 2n1 Two Post Lift offers 3 piece front and rear lifting arms for optimum asymmetric and symmetric loading opportunities.
Features
- Corrosion resistant protection - steel components are wheel-a-brator shot blasted and acid washed before a “double bake” powder coat finish is applied.
- Lifts higher to provide more under car work area - the 70-1/2’” / 1791mm long cylinder stroke provides 76” / 1930mm lift without adapters with a maximum attainable lift height of 86 5/8” / 2200mm.
- Flexible vehicle loading - 2 N 1 arm design uses three (3) piece “offset” front and straight (3) piece rear lifting arms for optimum asymmetric and symmetric loading opportunities.
- Reduced installation costs - field adjustable height and width can easily adapt to most installation dimensions.
- Premium North American Components - North American made Bucher 2HP / 1.5kw power unit, 3/8”/ 9.5 equalizing cables and 2 1/4” / 57mm ID hydraulic cylinders provide longer more dependable service life.
- Reduced vehicle setup time - Acme screw “drop in” style lift pads have a lowered height with rubber pad of 4” / 102mm and can be extended 3” / 76mm or 6” / 152mm using nickel plated drop in adapters. Power unit can be installed on either column.
- Quieter operation less than 75 decibels - rubber mounting grommets reduce power unit noise.
- Car door protection - 11” x 2” / 279mm x 51mm rubber door bumpers are mounted on the face of both lifting carriages to reduce door damage.
- More models to chose from - standard 2 N 1 design with 3 piece lifting arms, symmetric version with equal length straight arms, and choice of red or blue.
- Symmetric “wide” version can be field adjusted to 145 1/8” / 3686mm “extra wide”. Height reduces to 154 7/8” / 3934mm.
Technical
| Weight approx. | 2,300 | lbs |
| Color | Red and black | |
| Power supply | 230 Volts - 60 Hz - 1PH - 20 Amp | V/Hz/A |
| Dimensions (L x W x H) | 20.5 x 137 x 154 | inch |
