Vehicle Lifts
Click to view California Proposition 65 warning
With 317.5" runways, the HDS-27X is the first extended-length model in BendPak's super-duty four-post series. As a super-long lift that holds up to 27,000 lbs., this incredibly versatile lift accommodates massive Class 7 semi-trucks.
Features
- 27,000-Lb. Lifting Capacity.
- CE Approved and Certified. Meets or Exceeds the Standards Prescribed by European Standard EN-1493.
- Supersized 12" Diameter Cable Sheaves.
- Grease Nipples.
- Single Hydraulic Under-Runway Cylinder.
- Integrated Fow Restrictor.
- Spring-Loaded Safety Locks.
- Second Lock System on Constant Guard.
- Shipping Dimensions - 326"(L) x 27"(W) x 36"(H).
Technical
| Lifting height | 69.5 | inch |
| Lifting/lowering time approx. | 75 | s |
| Weight approx. | 6,944 | lbs |
| Color | Grey | |
| Power supply | 208-230V / 60 Hz / 1 Ph | V/Hz/A |
| Load carrying capacity | 27,000 | lbs |
| Dimensions (L x W x H) | 372.75 x 153.5 x 91.25 | inch |
