Vehicle Lifts
BendPak HDSO14AX 14,000-Lbs. Capacity Open-Front 4-Post Alignment Lift
$11,577.00
Click to view California Proposition 65 warning
We engineered the HDSO14AX alignment lift without a front crossbar, so operators can easily enter and exit from beneath the vehicle. Now the process of front-end adjustment becomes quick and trouble-free. This is a must for busy alignment bays. Additionally, for precise front-lift leveling, nothing beats our patented, adjustable front outrigger tubes. The infinitely adjustable pitch compensates for excessive loads and sloped floors. Rear-facing multi-caster slip plates and front-facing turn plates permit precise, free-floating alignment. This alignment lift features two recessed turn plate pockets that let you freely position the corrosion-resistant, galvanized turn plates. BendPak alignment lifts include strong, durable, and oversized 10.5" diameter cable sheaves within the runway and cross tubes, as well as 2.25" diameter sheave axles. These powerful components keep your car lift running for many years, far past the point other brands' lifts have already given out of required expensive parts replacements. BendPak runs four aircraft-quality steel cables (that measure in at a robust 1/2" diameter, 6 x 25), within the columns. They are literally the ultimate standard for high-quality cable construction and safe lifting. Alignments are often done by different mechanics in a busy shop. The multiple locking heights allow different people to work on the HDSO14AX alignment lift at the height appropriate for them. Since it's an open-front design, getting under is easy no matter how tall they are.
Features
- 14,000-Lbs. Lifting Capacity.
- CE Approved and Certified. Meets or Exceeds the Standards Prescribed by European Standard EN-1493.
- Heavy-Duty Turn Plates and Integrated Rear Slip-Plates Included.
- Automatic Leveling System.
- Multiple Auto-Leveling Locking Positions.
- Heavy-Duty Aircraft Cable.
- Internal “Anti-Sway” UHMW Slider Blocks in Each Column.
- Spring-Loaded Automatic Safety Locks.
- Runways Adjust For Different Tread Widths and Feature a Durable Matte Finish.
- Shipping Dimensions - 224"(L) x 28"(W) x 43"(H).
