Vehicle Lifts
Click to view California Proposition 65 warning
High-density UHMW rollers make the LR-60P a conveniently portable low-rise lift. If you're regularly shifting car lifts to different service bays or have limited space you need to diversify, a portable lift will make your garage operations that much easier. These amazingly durable wheels, and they're practically indestructible. One person can easily move the LR-60P around shops or garages, and the wheels never wear or need replacing. The LR-60P offers portability without adding bulk. The lift collapses to just 4" high, so low-stance vehicles have no problem clearing the frame. This small-footprint model is not only ideal for tight spaces, but for garages with limited equipment that need to work in different places around the shop, or simply store the lift out of the way. With the push of a button on the control panel, dual locks release on each frame of the LR-60P. The control panel keeps operators at a safe distance during descent, ensuring efficiency, peace-of-mind, and a safe, smooth-running lift at all times.
A dropped crossbar makes it easier to drive up and onto the frames. The center portion of each frame rises to engage the vehicle's OEM jacking points. Since the crossbar improves stability without slowing or hindering operations, Wheel Service and suspension work becomes a cinch. A steel channel runs along the base of the LR-60P. The added stability makes this an ideal lift for busy, active bays. With a five-year standard warranty and superior engineering put into the design, we guarantee you'll work without worry for as long as you own your BendPak. Integrated into the single hydraulic cylinder is a one-piece, pilot fitted, machined steel piston that is wrapped with specially designed, pressure loaded U-cup piston seals, backups, and wear bands that virtually eliminate any fluid bypass.
Features
- 6,000-lbs. Lifting Capacity.
- Tow Handle Makes it Easy to Move Lift from Bay to Bay.
- Electric / Hydraulic Power System.
- Rubber Lifting Blocks Included.
- Dropped Cross Bar for Added Clearance.
- Heavy-Duty Steel Channel Frame.
- Shipping Dimensions: 83"(L) x 74"(W) x 8"(H).
Technical
| Load carrying capacity | 6,000 | lbs |
| Lifting/lowering time approx. | 35 | s |
| Weight approx. | 920 | lbs |
| Color | Grey | |
| Power supply | 110 VAC / 50-60 Hz / 1 Ph | V/Hz/A |
| Dimensions (L x W x H) | 82 x 70.5 x 23 | inch |
