The revolutionary RL-8500 combination brake lathe uses independent DC servo motors to control the cross-feed and spindle feed drives, eliminating the need for complex mechanical gear boxes and transmissions typically found on mechanically-driven brake lathes.



Features

• Precision Electric DC Servo Motors Designed to Meet the Demanding Requirements of Industrial Motion Control.
• Quick-Change Adapter-Plus System with Built-In Springs Eliminates the Need for Conventional Bell Clamps and Cones.
• Works with Hubless Drums, Rotors (Center Hole Sized 2-5/32" – 4") and Composite Rotors (Center Hole Sized 4" – 6.25").
• Infinitely Variable Spindle and Cross Feed Speed Settings Allow for Quick Rough and Precision Finish Cuts.
• Simple Ergonomic Controls are Designed for Minimal Operator Movement.



Technical

Power supply	115 – 230 VAC, 50-60 hz, 1 Ph, 20 amp	V/Hz/A
Weight approx.	678	lbs
Dimensions (L x W x H)	45 x 38 x 29	inch
