Due to the high voltages involved in secondary ignition systems, it is not possible to make measurements by direct connection. Attempting to make a direct connection will almost certainly damage the measuring instrument.

The 733-MI074 is a capacitive pickup that simply connects around the insulation of an ignition circuit component such as a plug wire. This avoids the need for direct connection.

The 733-MI074 comes with a shielded 6 foot (1.8 m) lead and features a BNC connector for scope input . It is suitable for use with conventional ignition systems and most HEI and DIS systems.

Although ideal for use with a PicoScope automotive oscilloscope, the 733-MI074 pickup can also be used with most other makes of oscilloscope provided they have a waveform invert option.



Technical

Weight approx.	1	lbs
Dimensions (L x W x H)	9 x 7 x 3	inch
