Three car stacker.

Built to a higher standard of quality; made in Italy by O.ME.R S.p.A., a world leader in Vehicle Lift Manufacturing with over 40 years’ experience.

Compact design–utilizing a minimal footprint, optimizing effenciency and allowing for the maximum number of vehicles in a given space.

E ciency & Longer Life Time – The platform carriage is guided by wheels and reinforced nylon guides, reducing the friction between the column and carriage and lowering the power needed for operation. Channeled galvanized platforms reduce rust & drain water away from the vehicle below.

Flexibility – uniquely balanced and reinforced to allow vehicles to be parked facing either forward or backward, with no need for weight to be evenly distributed.

Safety and convenience –the electrically-actuated mechanical-locking device guarantees a safe locking position at 1” intervals, while the unique torsion bar ensures that the platform remains constantly parallel and can be safely stopped at any height.



Features

• Two direct lifting hydraulic cylinders on each platform sides.
• No chains or sprockets.
• Minimal footprint.
• 6'' only concrete depth needed.
• Sleek design.
• Easy to operate.
• Only 3 car stacker with two post in the market.



Technical

Dimensions (L x W x H)	13'8'' x 8'10'' x 16'4''	inch
Dimensions (L x W x H) carrier	13'8'' x 7' 4'' x 3''	inch
Operating pressure	max 140	bar
Power supply	208-220V 1ph 60Hz	V/Hz/A
Color	RAL 7040
Weight approx.	5000	lbs
Lifting/lowering time approx.	45	s
Lifting height	6' 9'' lower 6' upper	inch
Motor output	1.5 KW	kW
