Built to a higher standard of quality, made in Italy by O.ME.R S.p.A., a world leader in Vehicle Lift Manufacturing with over 40 years of experience.

Compact design–utilizing a minimal footprint, optimizing efficiency and allowing for the maximum number of vehicles in a given space.

Effciency & Longer Life Time – The platform carriage is guided by wheels and reinforced nylon guides, reducing the friction between the column and carriage and lowering the power needed for operation. Channeled galvanized platforms reduce rust & drain water away from the vehicle below.

Flexibility – uniquely balanced and reinforced to allow vehicles to be parked facing either forward or backward, with no need for weight to be evenly distributed.

Safety and convenience –the electrically-actuated mechanical-locking device guarantees a safe locking position at 1” intervals, while the unique torsion bar ensures that the platform remains constantly parallel and can be safely stopped at any height.



Features

• Two direct lifting hydraulic cylinders on the platform sides.
• No chains or sprockets.
• Minimal footprint.
• 4'' only concrete depth needed.
• Sleek design.
• Easy to operate.



Technical

Dimensions (L x W x H)	11'6'' x 8' 6.4'' x 9' 4''	inch
Dimensions (L x W x H) carrier	11' 6'' x 7' 6.6'' x 3''	inch
Operating pressure	150 bar max	bar
Power supply	208-220V 1ph 60Hz	V/Hz/A
Color	RAL 7040
Weight approx.	2500	lbs
Lifting/lowering time approx.	45	s
Lifting height	6' 10''	inch
Motor output	1.5 KW	kW



Options

817-5030176930	Photocell Control under Platform	$500.00	Add to cart
817-5030179985	Photocell to Controll Platform Travel	$500.00	Add to cart
