16K Capacity / Clearfloor / Super-Duty / 192" O.A. Height.



Features

• Heavy-duty 16,000-lb. lifting capacity supports large trucks, commercial vans, fleet vehicles, and EVs.
• Extra-tall 192-inch column height provides increased overhead clearance for taller vehicles and high-roof vans.
• Bi-Metric™ triple-telescoping arms allow both symmetric and asymmetric lifting configurations from one lift.
• Low-Pro™ front arm design reaches difficult OEM lifting points on lowered vehicles and EV battery platforms.
• Automatic Swing Arm Restraint System (ASARS) locks arms securely in place during lifting operations.
• Clearfloor layout eliminates floor obstructions for easier movement of jacks, carts, and shop equipment underneath vehicles.
• Expandable overhead beam design allows wide or narrow installation configurations to fit different shop layouts.
• Direct-drive hydraulic cylinders provide smooth lifting action with fewer moving components and reduced maintenance.
• Single-point safety lock release system improves operator convenience and streamlines lowering procedures.
• Self-lubricating UHMW polyethylene carriage bearings reduce friction and long-term wear.
• Includes stackable adapters and frame cradle pads for improved versatility across a wide range of vehicle types.
• ALI Certified and tested to meet strict industry safety and performance standards for professional service environments.



Technical

Dimensions (L x W x H)	176 x 147 x 193	inch
Power supply	208-230 V / 60 Hz / 1 Ph	V/Hz/A
Color	Gunmetal Gray
Weight approx.	3,150	lbs
Lifting/lowering time approx.	45	s
Lifting height	82	inch
Motor output	2.2	kW
Effective height	76	inch
Oil fill capacity	4	gallons
Load carrying capacity	16,000	lbs
Drive-over height	5	inch
