20K Capacity / Clearfloor / Super-Duty / 192" O.A. Height



Features

• Massive 20,000-lb. lifting capacity handles heavy-duty trucks, fleet vehicles, commercial vans, and large EVs.
• Extra-tall 192-inch columns provide exceptional overhead clearance for high-roof commercial vehicles and lifted trucks.
• Bi-Metric™ triple-telescoping arms support both symmetric and asymmetric lifting configurations.
• Low-Pro™ arm design reaches difficult OEM lifting points on lowered vehicles and EV battery platforms.
• Automatic Swing Arm Restraint System (ASARS) securely locks swing arms into position during lifting.
• Clearfloor configuration removes floor obstructions for easier movement of rolling shop equipment underneath vehicles.
• Expandable overhead beam allows wide or narrow installation layouts to better fit different shop spaces.
• Direct-drive hydraulic cylinders provide smooth lifting action with reduced maintenance requirements.
• Ergonomic single-point safety lock release simplifies lowering procedures and improves technician workflow.
• Heavy-duty aircraft-grade lifting cables provide long-term durability and dependable carriage synchronization.
• UHMW polyethylene carriage bearings are self-lubricating to reduce friction and wear over time.
• Includes stackable adapters, cradle pads, and adapter storage organizers for improved lifting versatility.



Technical

Dimensions (L x W x H)	179 x 148 x 193	inch
Power supply	208-230 V / 60 Hz / 1 Ph	V/Hz/A
Color	Gunmetal Gray
Weight approx.	3,600	lbs
Lifting/lowering time approx.	45	s
Lifting height	82	inch
Motor output	2.2	kW
Effective height	76	inch
Oil fill capacity	4	gallons
Load carrying capacity	20,000	lbs
Drive-over height	5	inch
