12K Cap. / Clearfloor / Standard / Triple-Telescoping Arms / 192" O.A. Height.



Features

• Massive 12,000-lb. lifting capacity handles heavy trucks, SUVs, vans, and EVs with ease.
• Extra-tall 193" overall height provides exceptional clearance for lifted trucks and commercial vehicles.
• Exclusive Bi-Metric™ swing arms support both symmetric and asymmetric lifting configurations.
• Triple-telescoping Low-Pro™ arms retract shorter and extend farther for better lifting-point access.
• Automatic Swing Arm Restraint System (ASARS) delivers over 2,000 lbs. of arm holding force for improved safety.
• Clearfloor design eliminates floor obstructions for easy movement of rolling equipment underneath vehicles.
• Low-profile arm design safely reaches lifting points on lowered cars and modern EVs.
• Expandable top beam allows wide or narrow installation configurations to fit different shop layouts.
• Ergonomic single-point safety release simplifies lowering operations for technicians.
• Dual hydraulic direct-drive cylinders provide smooth lifting performance and dependable operation.
• Self-lubricating Dura-Glide UHMW polyethylene bearing system reduces maintenance and wear.
• Includes stackable adapters, cradle pads, and adapter holders for versatile vehicle support setups.



Technical

Dimensions (L x W x H)	156 x 28 x 193	inch
Power supply	208-240 V / 60 Hz / 1 Ph	V/Hz/A
Color	Gunmetal Gray
Weight approx.	2,600	lbs
Lifting/lowering time approx.	45	s
Lifting height	82.5	inch
Motor output	2.2	kW
Oil fill capacity	3	gallons
Load carrying capacity	12,000	lbs
Drive-over height	4	inch
