Octa-Flex / 12K Capacity / Clearfloor.



Features

• World’s first two-post lift with eight fully adjustable telescoping lift arms for unmatched versatility.
• Patent-pending OctaFlex design combines traditional lifting arms with integrated powered lift-assist arms in one system.
• Auxiliary lift-assist arms can safely lift and maneuver EV battery packs, drivetrains, truck cabs, and heavy components.
• Lift-assist arms support up to 2,500 lbs. for ergonomic component handling and reduced technician strain.
• Triple-telescoping primary arms extend farther than traditional lift arms for expanded lifting-point coverage.
• Low-profile dropped-end arm receivers improve access to difficult OEM lifting points on EVs and low-clearance vehicles.
• Patent-pending Automatic Swing Arm Restraint System (ASARS) delivers more than 2,000 lbs. of holding force for enhanced safety.
• Bi-Metric reversible swing arms allow operators to configure the lift symmetrically or asymmetrically depending on the vehicle.
• Clearfloor design keeps the bay unobstructed for easier movement of transmission jacks, carts, and shop equipment.
• Single-piece columns and industrial-grade hydraulic cylinders are engineered for long-term durability and heavy-duty shop use.
• UHMW polyethylene load bearings never require lubrication, reducing maintenance requirements over time.
• Designed specifically for modern EV service, cab-off repairs, and advanced vehicle disassembly procedures without requiring additional lifting equipment.



Technical

Dimensions (L x W x H)	154 x 155 x 173.5	inch
Power supply	208-230 V / 60 Hz / 1 Ph	V/Hz/A
Color	Gunmetal Gray
Weight approx.	4,246	lbs
Lifting/lowering time approx.	45	s
Motor output	2.2	kW
Effective height	72	inch
Oil fill capacity	4	gallons
Load carrying capacity	12,000	lbs
Drive-over height	6.25	inch
