12K Cap. Parking Lift / Tandem Platforms / NARROW / Std. Rise - Short Platforms / SPECIAL ORDER.



Features

• Heavy-duty 12,000-lb. lifting capacity supports passenger cars, trucks, SUVs, and commercial vehicles.
• Open-center four-post design provides easier access for transmission service, driveline work, and undercar repairs.
• Dual-hub cable sheave system reduces cable stress and improves long-term lifting stability.
• Extra-long runways accommodate long-wheelbase trucks, vans, and fleet vehicles with ease.
• Multi-position safety lock system engages automatically as the lift rises for enhanced operator safety.
• Integrated rear slip plates simplify wheel alignment procedures and improve alignment accuracy.
• Built-in front turn plates support precise steering-angle adjustments during alignment service.
• Heavy-duty aircraft-grade lifting cables provide reliable synchronization and long-term durability.
• Push-button pneumatic safety lock release system streamlines lowering procedures for technicians.
• Rugged powder-coated finish resists corrosion, chemicals, and harsh shop environments.
• ALI Certified design meets demanding industry safety and performance standards for professional repair facilities.



Technical

Dimensions (L x W x H)	224 x 112 x 87	inch
Extension height	82	inch
Power supply	208-230 V / 60 Hz / 1 Ph	V/Hz/A
Track width	39 - 49	inch
Track length	189	inch
Color	Gunmetal Gray
Weight approx.	4,409	lbs
Lifting/lowering time approx.	55	s
Lifting height	82	inch
Motor output	2.2	kW
Effective height	76	inch
Oil fill capacity	5	gallons
Load carrying capacity	12,000	lbs
Drive-over height	5	inch
