20K Capacity 2-Post / Clearfloor / Super-Duty



Features

• Massive 20,000-lb. lifting capacity handles heavy-duty trucks, commercial vans, fleet vehicles, and large EVs with ease.
• Bi-Metric™ swing arms allow technicians to configure the lift symmetrically or asymmetrically depending on the vehicle.
• Expandable overhead beam supports both wide and narrow installation configurations for different shop layouts.
• Triple-telescoping swing arms provide extended reach and improved access to difficult OEM lifting points.
• Patented Automatic Swing Arm Restraint System (ASARS) delivers over 2,000 lbs. of holding force for enhanced stability and safety.
• Clearfloor configuration removes floor obstructions for easier movement of shop equipment and transmission jacks.
• Dual-drive hydraulic cylinders provide smooth lifting performance and controlled lowering speeds.
• Mechanical safety locks automatically engage every four inches during lifting for improved operator protection.
• Single-point safety lock release system streamlines lowering procedures and improves technician efficiency.
• High-strength multi-face column construction improves rigidity and resists twisting under heavy loads.
• Includes a 12-piece adapter set for accommodating a wide range of chassis and lifting-point configurations.
• ALI Certified design meets demanding industry safety and performance standards for professional service facilities.



Technical

Dimensions (L x W x H)	179 x 148 x 169	inch
Power supply	208-230 V / 60 Hz / 1 Ph	V/Hz/A
Color	Gunmetal Gray
Weight approx.	3,350	lbs
Lifting/lowering time approx.	45	s
Lifting height	82.75	inch
Motor output	5	kW
Effective height	76.5	inch
Oil fill capacity	4	gallons
Load carrying capacity	20,000	lbs
Drive-over height	5	inch
