The measuring slide’s carrier forms the basis of the measuring arm. It runs on wheels which makes it easy to move to different positions along the measuring bridge.The measuring arm constitutes the actual measuring unit. It comprises three arms: The center arm is movable in the horizontal plane. It is mounted on a vertical axis on the measuring slide’s carrier. The center arm can rotate endless. The middle arm is mounted on a vertical axis on the center arm. The outer arm with a parallel movement arm is mounted on a horizontal axis at the end of the middle arm. At the other end of the parallel movement arm there is a measuring stylus holder for different measuring tubes which hold the measuring adapters as specified on the Data Sheets.
