The 3:1 ratio Panther® pump is suitable for simultaneous fluid distribution of up to five dispense points, or for pumping to distances of up to 500 feet.
The Panther's air motor features a precision air reversing valve mechanism with dual valve ports for improved high speed breathing. It also contains a positive trip detent spool mechanism that eliminates stalling (blowing air) when the pump is caught between strokes.
The Panther® pumping assembly features a nitrided steel pump rod and foot valve for superior wear and corrosion resistance. The pump's exterior is constructed from aircraft grade extruded aluminum for an outstanding strength-to weight ratio. The pump also has high quality Buna-N seals and is packaged in a pump that has proven reliable yet easy to service and maintain.
Features
- Suitable for simultaneous fluid distribution of up to five dispense points, or for pumping to distances of up to 500 feet.
- Pump delivery with SAE 10W-30 oil, 68º F, 100 PSI air pressure and free flow - 8 gal/m (30 l/m).
- Air consumption (100 PSI and 4 G/M) 19.70 SCFM.
- Max fluid stall pressure @150 PSI air 490 PSI (33.8 bar).
- Wetted materials - Carbon steel, Buna-N™, stainless steel, nickel plated steel, nylon, ultrathane, zinc plated steel, and aluminum.
- 34 Cycles per Gal
- Effective air piston diameter 2.5" (63.5 mm)
- Air inlet - 1/4" NPT (F)
- Fluid inlet - 1" NPT (F), 1-1/2" NPT (M)
- Fluid outlet - 3/4" NPT (F)
Technical
| Weight approx. | 20 | lbs |
| Power supply | Air | V/Hz/A |
| Dimensions (L x W x H) | 23-1/2 H | inch |
